-Clean X2 26" 2017 Bike.

-Frame constructed in high quality 6061 T6 + 7075 T6 aluminium alloy.

-New crankset BB30 3P included, improves stiffness and weight to the máximum and the maintenance is so much easier than before.

-Special dropouts. Allows the use of the new chain tensioner allows the rear wheel to be always in the same position, being perfect for the brake performance.

-Tapered headtube, being 1 1/8” in the top, and 1/5” in the bottom, improving weight and stiffness.

-Clean T13 levers combined with Magura cylinders.

-New concept, 100% integrated CNC brake mounts on tubing.

-New hydroformed Downtube.

FRAME CHARACTERISTICS:

-Frame: Clean X2. Aluminio 6061 T6 + 7075 T6.

-Fork: Clean X2. Aluminio 7005 T6. Tapered. HS.

-Weight: 7990 gr.

GEOMETRY:

-Wheelbase: 1090mm.

-BB high: +67mm.

-Chainstay: 380mm.

-Head angle: 72º.

-Reach: 670mm.

TIRES:

- Rims: Clean High Profile.

-Hubs: Clean Expert Hubs. 100mm / 116mm.

-Spokes: 1.8mm Black.

-Nipples: 16G Aluminium Red.

-Front tyre: Monty Pro Race.

-Rear tyre: Monty Pro Race.

-Front tube: Maxxis Extralight.

-Rear tube: Maxxis Extralight.

COMPONENTS:

-Handlebar: Clean ALU. 103mm total rise.

-Grips: Clean Foam. Extrathin.

-Stem: Clean 145x25.

-Headset: Clean Tapered. Superlight. Semi integrated.

-Brakes: Clean T13 + Magura cyclinders.

-Clamps: Clean Waserless + Clean X2 26".

TRANSMISSION:

-Bottom Bracket: Clean 3P Crankset. 30mm axle. Press Fit. Full CNC. 170mm.

-Pedals: Clean Single Cage.

-Chain: KMC 810SL.

-Chain tensioner: Clean Integrated. 7075 CNC plate. 11T plastic wheels.

-Freewheel: 135.9. 18T. Shimano HG Splined interface.

-Sprocket: Clean 15T.
