-Made of aerospace 6061-T6 aluminium.
-Designed for semi-integrated headset.
-120mm high CNC machined headtube.
-68mm wide bottom bracket shell for ISIS bottom bracket.
-CNC machined post mount rear disc brake support suitable for 160mm rotor includes integrated rear dropout.
-CNC machined horizontal dropouts distanced 116mm apart come supplied with steel snail cam bolts.
-Sandblasted and black anodized finish with Jitsie graphics.
-Frame comes supplied with lightweight silicon seat plug.
-Frame allows for the Jitsie aftermarket seat to be installed.
GEOMETRY
-Wheelbase: 1010 mm.
-Chainstay length: 350 mm.
-Bottom bracket height: 80 mm.
-Headtube: 120 mm.
-Headtube angle: 71.5°.
(geometry based on Jitsie Varial fork 370mm and +45mm offset).
- Weight 1505 gr.
